HP 2530-48G Switch

HP 2530-48G Switch

Tipo interruttore: Gestito
Switch layer: L2
Supporto qualità del servizio (QoS): Sì
Gestione web-based: Sì
Quantità di porte RJ-45: 48
Tipo di porte RJ-45: Gigabit Ethernet (10/100/1000)
Quantità di slot per modulo SFP: 4
Dimensions & Weight
Depth: 25.4 cm
Height: 4.45 cm
Weight: 3.08 kg
Width: 44.3 cm
Environmental Parameters
Humidity Range Operating: 15 - 95% (non-condensing)
Humidity Range Storage: 15 - 90% (non-condensing)
Max Operating Temperature: 45 °C
Max Storage Temperature: 70 °C
Min Operating Temperature: 0 °C
Min Storage Temperature: -40 °C
Expansion / Connectivity
Interfaces: 48 x 1000Base-T RJ-45 ¦ 4 x SFP ¦ 1 x management RJ-45
General
Authentication Method: RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Compliant Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3az
Device Type: Switch - 48 ports - Managed
Enclosure Type: Desktop, rack-mountable, wall-mountable 1U
Encryption Algorithm: SSL
Features: Flow control, DHCP support, BOOTP support, ARP support, VLAN support, auto-uplink (auto MDI/MDI-X), port mirroring, IPv6 support, half duplex mode, full duplex mode, SNTP support, sFlow, Multiple Spanning Tree Protocol (MSTP) support, Access Control List (ACL) support, Multicast Suppression, STP Root Guard, LLDP support, dual firmware images, Class of Service (CoS), Generic Attribute Registration Protocol (GARP)
Flash Memory: 128 MB
Jumbo Frame Support: 9220 bytes
MAC Address Table Size: 16000 entries
Performance: Throughput: 77.3 Mpps ¦ Switching capacity: 104 Gbps
Ports: 48 x 10/100/1000 + 4 x Gigabit SFP
Processor: 1 x ARM: 800 MHz
RAM: 256 MB DDR3 SDRAM
Remote Management Protocol: SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, SSH-2, CLI
Subtype: Gigabit Ethernet
Miscellaneous
Compliant Standards: FCC Class A certified, CISPR 22 Class A, CISPR 24, EN 61000-3-2, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, VCCI Class A ITE, EN 61000-3-3, EN55024, UL 60950-1, IEC 60950-1, EN 60950-1, CSA C22.2 No. 60950-1, EN 55022 Class A
Power
Power Device: Internal power supply
Voltage Required: AC 120/230 V (50/60 Hz)
